12 volt DC
750mm cable
Connections: For 25mm (1") and 28mm (1 1/8") bore hose.
Dimensions: 111mm high, 64mm x 74mm.
Current Draw: 3.7(amps)
Fuse Size: 6(amp)
Output: Up to 69 litres/minute (15 gallons/minute) without check valve. Max recommended discharge head 2m.
Compact pump for smaller vessels.
Tough plastic body.
Quick release inlet strainer allows rapid cleaning.
Low amp draw conserves batteries.
Built-in Thermal Cut-Off. Motor rated for 1500-hour life.
Check Valve included for Back Flow Prevention.
Vented body to prevent air locking.
Threaded port for easier installation and maintenance.
For automatic operation use Rule Float Switches.
Base not interchangeable with old range but can be fitted to existing screw holes.
Packaged Dimensions: L:18.00 x H:9.00 x W:17.00cm
Actual Weight: 0.41 Kg (Approx. 0.61 Kg packed)
